Brief introduction of Horizontal centrifuge

The contact part of the material is made of 304 stainless steel, which is used to separate the fibers from the treated material, realize initial solid-liquid separation and further refine the material.

The working principle of the horizontal spiral sedimentation centrifuge

The mixture enters the drum through the feed pipe and the spiral discharge port. Under the centrifugal force generated by the high-speed rotation of the main engine, solid particles with larger specific gravity are deposited on the inner wall of the drum, and the spiral blades moving relatively to the drum continuously scrape the solid particles deposited on the inner wall of the drum and push them out of the slag discharge port, and the separated clear liquid flows out of the drum through the weir plate opening.

Main technical specifications of Horizontal centrifuge

Processing capacity About 5-7 Tons/ Hour, customized
Drum diameter 450 mm
Working length of drum 2000mm
Maximum drum speed 3300 r/min
Draw ratio 4.4
Differential rotation speed 0-35 r/min (Stepless adjustable)
Main motor power 37 kW
Auxiliary motor power 11 kW
Net weight of horizontal screw machine About 4500 kg
Dimensions (L*W*H) 4400*1160*1300mm
